17" Touch Panel PC IPPC-6172A - Core i3/i5/i7
View larger
17" Touch Panel PC IPPC-6172A - Core i3/i5/i7
17" Touch Panel PC Advantech IPPC Series, Processor Intel Core i3/i5/i7, 2 x PCI (half-length), Reader/Writer DVD (optional)
Features
| Manufacturer | Advantech |
| Series | IPPC |
| Screen size | 17" |
| Screen Ratio | 4/3 |
| Max Resolution | 1280 x 1024 |
| Brightness | 350 cd/m2 |
| Contrast Ratio | 1000:1 |
| LCD Color | 16.7 M |
| Viewing Angle | 170/160 |
| Touch Screen | Yes |
| Touchscreen Technology | Resistive |
| Front face protection | IP65 |
| Fanless | No |
| CPU | Intel Core i3-4330 Intel Core i5-4570S Intel Core i7-4770S |
| Processor Core | 2 4 |
| Processor Frequency | 3.5 GHz (Core i3) 2.9 GHz (Core i5) 3.1 GHz (Core i7) |
| Maximum RAM | 32 GB |
| Ram Type | DDR3 SO-DIMM |
| Storage | Compact Flash HDD SSD |
| OS Supported | Windows 7 Windows 8.1 Windows 10 |
| Ethernet Port(s) | 2 |
| RS-232 Port(s) | 3 |
| RS-232/422/485 Port(s) | 1 |
| USB 2.0 Port(s) | 1 |
| USB 3.0 Port(s) | 4 |
| Display Port Output | 1 |
| DVI Output | 1 |
| Sortie(s) VGA | 1 |
| Audio Output | Yes |
| Other Port(s) | 2 x PS/2 1 x Mic-in |
| PCI Expansion(s) | 2 |
| Speaker | No |
| Power Input | 100 ~ 240 VAC |
| Power Adapter 100-250V | No |
| Power consumption | 350 W |
| Operating Temperature | 0 ~ 50°C |
| VESA Mounting | No |
| RoHS | Yes |
| Certification | UL, CE, FCC, CCC, BSMI |
